I’ll be frank with you. I saw my friend wearing a similar dress at preschool pickup and I stared quite a long time at bust dart placement and elastic channeling before I said, “I could hack the Hinterland Dress to make that!” Fortunately my friend is also a sewist, and as such, continued to be my friend after the encounter. ;)
I REALLY love this dress. I plan to take it as one of 9 items of clothing on a three week trip to Europe this summer. Follow along over on Instagram to see how versatile it can be. Because it’s a V-neck, it layers very nicely under other tops, and because it’s black linen, it should be easy to care for and cool to wear. It adds a little “fancy and fitted” to the typical Hinterland silhouette with the help of waist darts and an elastic channel in the back.
You’ll learn a lot about pattern manipulation as you sew your way to a much-loved dress! Be sure to set aside a few hours to trace and hack your pattern pieces. You’ll be changing the position of a bust dart, re-drafting a bias facing and widening and lengthening a sleeve. This isn’t speedy sewing prep, but it isn’t difficult, and I promise you’ll cherish the result. Thank you so much to Judith for putting together this amazing tutorial!
Before you get started, check the fit of the bodice, either by making a quick muslin or doing your usual adjustments. For example, I’ve made the Hinterland dress before and I know that I’ll cut a size 10, and make a small adjustment to the shoulder area. I would do that adjustment now, before I continue with this tutorial.
You’ll need to trace off these 8 pattern pieces to start:
Front Bodice w/Sleeve
Back Bodice w/Sleeve
Front and Back Skirt (same pattern piece)
Full Front Placket
Full Front Placket Interfacing
Neck Facing (leave some extra paper on the ends for your adjustments)
You’ll also need some spare pattern paper, clear tape (like Scotch Magic Tape), a ruler (and a curved ruler, if you have one), paper scissors and a sharp pencil.
The corresponding image is shown above the written instructions. Note that the pattern pieces are shown at 1/3 scale.
Draw in the seam allowances on the Front Bodice and Back Bodice neck, shoulder, center front, and waist seams (all ⅝” except the waist, which is ½”), and on the whole Sleeve (⅝”, hem is ¼” plus ¾”). You’re going to be working your adjustments from the seam lines, not the cut edges, so marking these seam allowances accurately is very important.
2. On the Front Bodice neckline at Center Front, make a mark ½” down from the neck seam line (or more than ½”, depending on how low you’d like your neckline to go. On the modeled black dress, the neckline was lowered by 2” (5.1 cm). Connect this mark to the original neckline near the shoulder with a gently curved line. If you use a straight line here, it will look very strange on your body. (If you don’t have a curved ruler and you’re not happy with your lines, try using a printable curved ruler. https://www.onthecuttingfloor.com/french-curve-printable-template/ And if you’ll be doing much pattern hacking, I strongly recommend investing in a good set of curved rulers!)
Line up the Back Bodice to the Front Bodice, matching seam lines, along the shoulder seam, and blend the neckline curve to meet the original neckline at the Center Back.
You’ll need to shorten the placket pieces the same amount that you lowered the neckline at the beginning of this step.
3. To prevent gaping at the front neckline, draw a line from the center of the new neckline to the bust apex. Draw another line through the center of the bust dart to the apex.
Cut along these two lines, leaving a small hinge of paper connected at the apex, so that you can pivot these pieces. Overlap at the neckline ¼” - this will open up the bust dart slightly. Tape this overlap in place, but don’t tape the bust dart yet.
4. Mark a line from the bust apex to the waist, parallel to the grainline. You have already cut open the side dart in the previous step, and now you’re going to close it and make a new waist dart.
Cut up from the waistline to the bust apex along your new line, leaving a hinge point at the apex. Cut out the side dart intake (the triangle that corresponds to your size) and pivot the lower side of the pattern until the dart is closed. Tape in place. As you do this, the new waist dart will open along the waistline.
Tape paper behind the open dart. Now mark a new line from the bust apex to the waist, down the center of the dart. Measure 1” down this line from the apex and make a small mark across the line, to mark the end of the sewn dart. Draw in the new dart legs.
To true up the seam allowance, fold the pattern piece with the dart “pressed” towards Center Front, and cut along the waist cut line. As you open the paper, you’ll see the dart intake is shaped so that it will fit neatly into the seam allowance once the dart is sewn and pressed.
5. For the neckline finish, you’re going to be making a facing pattern. You can use the Neck Facing pattern as a starting point, but you’ll need to re-measure the length. Placing your ruler on its edge so that you’re measuring the sewing line (NOT the cut edge of the pattern piece, and not the seam allowances at the shoulder), measure the front neckline and back neckline, and the seam allowance at the center front (CF.)
Double this measurement and subtract ½”. (This will keep the facings slightly smaller than the neckline, so you don’t have any unsightly stretching out of the facing). The measurement that you have now is what you’ll use as the finished length of the Neck Facing, so measure your pattern piece and add or subtract to make it the correct length, centering the measurement over the center back (CB) double notches on the pattern piece. Don’t trim that extra paper off the end yet!
Now you’ll need to add a small triangle to account for the angle of the V-neck. Fold the facing in half lengthwise and place on top of the bodice so that the seam lines match at CF neck point.
See how you need to add a triangle shape? This is your new cut line, for both ends of the facing.
6. Set aside the Front and Back Bodices, and grab the Cap Sleeve pattern piece. You’ll need a piece of paper larger than the pattern piece ready, since we’re adding a bit to the sleeve hem circumference in this step.
½” from the underarm seam, mark a line parallel to the underarm seam, on the front and the back of the sleeve. Cut along the line up to the armscye seam allowance, and into the seam allowance from the other side, leaving a hinge point on the seam line.
Spread this cut line open ¼”, and tape a small piece of pattern paper behind to secure. (Don’t tape it to the big piece of paper yet!)
Lengthen the sleeve 1” (this gets you to the original cut line), and don’t add a seam allowance yet. (Note that you could lengthen more here if you’d like - just add some paper to the bottom. The sleeves were lengthened by 2” for the black dress in the photos.)
8. Parallel to the grainline, mark a line
from the shoulder apex notch to the sleeve hem
from the single notch on the front of the sleeve to the hem
halfway between the front notch and the shoulder apex notch, to the hem
from the top notch in the double notch to the hem
halfway between the double notch and the shoulder apex to the hem
You now have 5 lines parallel to the grainline. Cut up each line from the hem to the seamline. Cut into the seam allowance to the seamline on each line, leaving a hinge point on the seamline.
Carefully tape the section that has the grainline to your pattern paper. Spread each section apart ½”, at the hem, carefully keeping the hinge intact. Tape the sections in place. (This adds 2 ½” to the total hem measurement of the sleeve. If you want to spread more or less to change the flare of the sleeve, just be sure to distribute the measurements evenly).
Straighten the underarm seams. Add a ¼” plus ¼” seam allowance along the hem edge for a turn and turn hem.
Smooth the Armscye seam, and the Sleeve is ready!
9. For the Back Waist Elastic channel, you’ll be making a new pattern piece. It will be 2 ¼” high (for ½” wide elastic), and as wide as the Back Bodice measures 1 ¼” above the waist seam. The grainline is the same as the Back Bodice. Your cut length for the back elastic is the width of the Back Bodice at waist less 3 ½”.
(If you want to use different elastic, the height of the piece will change according to the difference between your elastic and ½”. For example, if you use ¾” elastic, the Back Waist Elastic Channel will be 2 ¾” high.)
You can follow the instructions as written for a Full Front Placket, with the following exceptions:
Before Step 1
Staystitch the neckline and armhole edges.
For the Back Waist Elastic Channel, fold the Channel in half lengthwise. Press well. Line up the bottom edge with the bottom edge of the WRONG SIDE of the Back bodice, right side of the Channel piece facing up, centers matching, and pin in place. Edgestitch along the folded edge to secure the Channel to the Back Bodice, sewing from the edge to the edge of the bodice. With a 7/16” (1 cm) seam allowance, stitch the channel to the Back Bodice at the waist. Feed the elastic through the channel and secure well in both side seam allowances. Now you can continue sewing with the Back Bodice as instructed.
In Step 2, you’ll be sewing waist darts instead of side darts. Sew as instructed, but press the dart intake towards the Center Front.
Skip Step 4
Step 6 is as written, though your facing should fit the neck almost exactly. You may pull the facing ever so slightly to ease the bodice to the facing length.
In Step 9, the sleeve hem allowance is a ¼” turn and turn hem. Sew ¼” from the edge of the sleeve, and use this line of stitching to turn the raw edge toward the wrong side ¼”. Fold under ¼” more, press well, and pin in place. Edgestitch along the folded edge to hem.
In Step 12b, when gathering the back of the skirt to fit the back bodice, make sure you gather the skirt to fit the back bodice when stretched out - in other words, the original width of the bodice before you added the elastic. When sewing the back skirt to the back bodice, you should work in sections and gently pull the elastic taut while sewing.
In Step 13c, when finishing the top edges of the plackets, mark a line that follows the diagonal edge of the neck facing, as shown above. Make sure your diagonal line is exactly mirrored (same angle and length) on the opposite placket. Sew along the line and trim the seam allowance, then continue with the instructions to finish your dress.
And … you’re done! Be sure to tag your creations with #hinterlanddress and #hinterlandhackathon!
